Timer/Counter 0


Mode 0

Timer/Counter 0: Mode 0

One of the standout features of Timer/Counter 0 is its ability to generate interrupts. When it overflows, it can trigger an interrupt, allowing the microcontroller to respond immediately, making it invaluable for real-time applications.

at89c51 timer counter 0

Beyond these functionalities, Timer/Counter 0's integration into the AT89C51 ensures efficient power management, allowing it to run or halt based on the system's requirements. Whether it's used in precision timing control, event counting, or generating PWM signals, Timer/Counter 0 in the AT89C51 remains a cornerstone in the realm of embedded systems, offering developers a blend of flexibility and precision.

Belonging to the 8051 family, the AT89C51 is a low-power, high-performance microcontroller. With its in-built ROM, RAM, timers, serial ports, and versatile I/O ports, it serves as the brain for numerous embedded system applications. But today, we're focusing on one specific aspect: Timer/Counter 0.

At its core, Timer/Counter 0 can operate in two primary modes: as a timer to generate delays or as a counter to count external events. Think of it as a stopwatch. In 'timer mode,' it measures the passage of time. In 'counter mode,' it keeps track of the number of times an external event occurs.

Diving into Timer Modes

The AT89C51 offers multiple timer modes -

Mode 0

An 8-bit timer. Envision it as a short race where the finish line comes up quickly.

Mode 1

A 16-bit timer. This is akin to a marathon, providing a more extended range for timing operations.

Mode 2

An 8-bit auto-reload timer. Imagine a looped track where, after each lap, the race restarts automatically.

Mode 3

This mode splits Timer/Counter0 into two separate 8-bit timers/counters. Think of it as having two stopwatches instead of one.

Counter Modes: Counting External Events

When used as a counter, Timer/Counter0 counts the number of external pulses fed into it. It's like a turnstile at a stadium, counting the number of people entering the venue.

Control Registers

There are two important registers to control Timer 0, the TMOD (Timer Mode) and TCON (Timer Control) registers.

TMOD (Timer Mode Control Register)

The TMOD register is an 8-bit register used for selecting the operation mode of Timer 0.

Bit Number 7 6 5 4 3 2 1 0
Symbol GATE1 C/T1# M11 M10 GATE0 C/T0# M01 M00
Description External input for Timer 1 Timer or Counter Selector for Timer 1 Timer 1 Mode Select bit 1 Timer 1 Mode Select bit 0 External input for Timer 0 Timer or Counter Selector for Timer 0 Timer 0 Mode Select bit 1 Timer 0 Mode Select bit 0

TCON (Timer Control Register)

The TCON register is another 8-bit register used to control Timer 0.

Bit Number 7 6 5 4 3 2 1 0
Symbol TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0
Description Timer 1 Overflow Flag Timer 1 Run Control Bit Timer 0 Overflow Flag Timer 0 Run Control Bit External Interrupt 1 Edge Flag External Interrupt 1 Type Control Bit External Interrupt 0 Edge Flag External Interrupt 0 Type Control Bit

TH0 (Timer 0 High Byte Register)

The TMOD register is an 8-bit register used for holding the high counting value of the timer.

Bit Number 7 6 5 4 3 2 1 0
Symbol Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Description - - - - - - - -

TL0 (Timer 0 Low Byte Register)

The TMOD register is another 8-bit register used for holding the lower 8 bits of counting value of the timer.

Bit Number 7 6 5 4 3 2 1 0
Symbol Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Description - - - - - - - -

Configuration Steps


a. Set the Timer Mode

You need to decide whether you want Timer 0 to work in Timer mode or Counter mode. This is done by setting or clearing the C/T0 bit of the TMOD register.

b. Choose the Operating Mode

Timer 0 can be configured in one of the four modes

Mode 0

13-bit Timer mode

Mode 1

16-bit Timer mode

Mode 2

8-bit auto-reload mode

Mode 3

Split Timer mode

This is set using the M1 and M0 bits of the TMOD register.

c. Loading the Timer Registers -

If you're not using the auto-reload mode, load the TH0 and TL0 registers with the required initial value.

d. Start/Stop the Timer

To start the timer, set the TR0 bit of the TCON register. To stop it, clear the TR0 bit.

Flags and Interrupts

The TF0 bit in the TCON register will be set when Timer 0 overflows. This can be used to generate an interrupt if interrupts are enabled.

IE Register

EA - - ES ET1 EX1 ET0 EX0
Symbol Position Function
EA IE.7 Disables all interrupts. If EA=0, no interrupt is acknowledged. If EA = 1, each interrupt source is individually enabled or disabled by setting or clearing its enable bit.
IE.6 Reserved
IE.5 Reserved
ES IE.4 Serial Port interrupt enable bit
ET1 IE.3 Timer 1 interrupt enable bit
EX1 IE.2 External interrupt 1 enable bit
ET0 IE.1 Timer 0 interrupt enable bit
EX0 IE.0 External interrupt 0 enable bit

User software should never write 1s to reserved bits, because they may be used in future AT89 products.

Loading...

Timer/Counter 0: Mode 0

AT89C51 microcontroller offers various modes for its timers, and Timer/Counter Mode 0 is one of the most fundamental yet powerful modes you can use. It provides an 8-bit or 13-bit timer or counters that serve various purposes, including generating time delays, event counting, and even pulse generation.

This article aims to dissect the Timer/Counter Mode 0 in AT89C51 by explaining its configuration through TMOD and TCON registers, how to program it, and its real-world applications. Whether you are a novice or a seasoned embedded developer, this guide will offer you comprehensive insights to harness the full potential of Timer/Counter Mode 0 in AT89C51.
